Asus Intel TUF GAMING B560-PLUS WIFI LGA1200 ATX Motherboard


CPU
Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® 14 nm CPU
Supports Intel® Turbo BoostTechnology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to www.asus.com forCPU support list.
** Intel® Turbo Boost MaxTechnology 3.0 support depends on the CPU types.
Chipset
B560
Memory
DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133MHz Non-ECC, Un-buffered Memory*
Dual Channel MemoryArchitecture
Supports Intel® ExtremeMemory Profile (XMP)
OptiMem II
* 10th Gen Intel® Core™i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run atthe maximum transfer rate of DDR4 2666MHz.
* 11th Gen Intel® processorssupport 3200/2933/2800/2666/2400/2133 natively.
* Refer to www.asus.com for the MemoryQVL (Qualified Vendors Lists), and memory frequency support depends on the CPUtypes.
Graphics
* Graphics specificationsmay vary between CPU types.
** Intel® 11th & 10thprocessors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Pleaserefer to www.intel.com for any updates.
*** Only Intel® 11th processorssupport HDMI™ 2.0 with max. resolution of 4K@60Hz, others will only supportHDMI™ 1.4 with max. resolution of 4K@30Hz .Please refer to www.intel.com forany updates.
ExpansionSlots
1 x PCIe 4.0/3.0 x16 + 1 x PCIe 3.0 x16 (max. x4)
Intel®11th &10th Gen Processors*
1 x PCIe 4.0/3.0 x16slot(s)**
- Intel® 11th processorssupport PCIe 4.0 x16
- Intel®10th processorssupport PCIe 3.0 x16
Intel®B560 Chipset
1 x PCIe 3.0 x16 slot (supportsx4 mode)*
3 x PCIe 3.0 x1 slots
* Enable RST PCIe StorageRemapping for PCH attached PCIe slots to activate Intel® Optane Memory.
Storage
Intel®11thGen Processors
M.2_1 slot (Key M), type2242/2260/2280/22110
- Only Intel® 11thprocessors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs
Intel®B560 Chipset
M.2_2 slot (Key M), type2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*
6 x SATA 6Gb/s ports
To enable Intel® Optane™Memory (Hybrid Storage device), it must be installed in PCH-attached slots withIntel® Rapid Storage Technology.
* M.2_2 slot shares bandwidthwith SATA_2.When M.2_2 slot is operating in SATA mode, SATA_2 will be disabled.
USB
Rear USB:Total 8 ports
2 x USB 3.2 Gen 2 ports (2 xType-A)
3 x USB 3.2 Gen 1 ports (2 xType-A + 1x Type-C®)
3 x USB 2.0 ports (3 xType-A)
1 x USB 3.2 Gen Gen 1connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 headersupports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers supportadditional 4 USB 2.0 ports
Audio
Realtek ALC897 7.1 SurroundSound High Definition Audio CODEC*
- Supports: Jack-detection,Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192kHz playback"
AudioFeatures
- Audio Shielding
- Rear optical S/PDIF outport
- Premium Japanese audiocapacitors
- Dedicated audio PCB layers
BackPanel I/O Ports
2 x USB 3.2 Gen 2 ports (2 xType-A)
3 x USB 3.2 Gen 1 ports (2 xType-A + 1x Type-C®)
3 x USB 2.0 ports (3 xType-A)
1 x DisplayPort
1 x HDMI™ port
1 x ASUS Wi-Fi Module
1 x Realtek 2.5Gb Ethernetport
5 x Audio jacks
1 x Optical S/PDIF out port
InternalI/O Connectors
Fanand Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
3 x 4-pin Chassis Fanheaders
Powerrelated
1 x 24-pin Main Powerconnector
1 x 8-pin +12V Powerconnector
Storage related
2 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen Gen 1connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 headersupports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers supportadditional 4 USB 2.0 ports
2 x AURA Addressable Gen 2headers
2 x AURA RGB headers
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header(AAFP)
1 x 20-3 pin System Panelheader with Chassis intrude function
1 x Thunderbolt™ header
SpecialFeatures
ASUSTUF PROTECTION
- Digital power design withDr. MOS
- Enhanced DRAM OvercurrentProtection
- ESD Guards
- TUF LANGuard
- Overvoltage Protection
- SafeSlot Core+
- Stainless-Steel Back I/O
ASUSQ-Design
- M.2 Q-Latch
- Q-DIMM
- Q-LED (CPU [red], DRAM[yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUSThermal Solution
- M.2 heatsink
- VRM heatsink design
ASUSEZ DIY
- ProCool
- Pre-mounted I/O shield
AURASync
- AURA RGB header(s)
- Addressable Gen 2 RGBheader(s)
SoftwareFeatures
ASUSExclusive Software
Armoury Crate
- AURA Creator
- AURA Sync
- Two-Way AI NoiseCancelation
AI Suite 3
- Performance And PowerSaving Utility
TurboV EVO
EPU
Digi+ VRM
Fan Xpert 4
- EZ update
TUF GAMING CPU-Z
AI Charger
ASUS Turbo LAN
DAEMON Tools
DTS Custom for GAMINGHeadsets
MyAsus
Norton Anti-virus software(Free Trial version)
WinRAR
UEFIBIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
BIOS
128 Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PME, PXE
Accessories
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS Wi-Fi movingantennas
1 x M.2 Rubber Package(s)
1 x M.2 SSD screw package(s)
1 x TUF Gaming sticker
InstallationMedia
1 x Support DVD
Documentation
1 x TUF Certification card
1 x User manual
OperatingSystem
Windows 10 64bit
