Asus Intel PRIME H610M-E D4-CSM LGA1700 mATX Motherboard

In stock
Motherboard
Asus
RM499.00 RM475.00
-5%
RM475.00
customers are viewing this product








Highlights



- Model PRIME H610M-E D4-CSM

- Intel® LGA 1700 socket: Ready for 12th Gen Intel®processors

- Comprehensive cooling: PCH heatsink and Fan Xpert 2+

- Ultrafast connectivity: 32Gbps M.2 slot, Realtek 1 GbEthernet and USB 3.2 Gen 1

- 5X Protection III: Multiple hardware safeguards forall-round protection

- ASUS Control Center Express (ACCE) for easier IT endpointmanagement



Product Description​

Specification

ASUS Corporate Stable Model (CSM) is a commercial programdesigned to provide stable and reliable motherboards. Offering up to 36-monthproduct lifecycle support and 6-month end-of-life notice to allow sufficientlead times for your organization to get ready for product transitions. Eachpurchase of an ASUS CSM motherboard comes with ASUS Control Center Express -server-grade IT management software.



CPU

Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium®Gold and Celeron® Processors*

Supports Intel® Turbo Boost Technology 2.0 and Intel® TurboBoost Max Technology 3.0**

* Refer to www.asus.com for CPU support list.

** Intel® Turbo Boost Max Technology 3.0 support depends onthe CPU types.



Chipset

Intel® H610 Chipset



Memory

2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133Non-ECC, Un-buffered Memory*

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Profile (XMP)

* Actual memory data rate depends on the CPU types and DRAMmodules, for more information refer to www.asus.com for the Memory QVL(Qualified Vendors Lists).



Graphic

1 x DisplayPort**

1 x D-Sub port

1 x HDMI® port***

* Graphics specifications may vary between CPU types. Pleaserefer to www.intel.com for any updates.

** Supports max. 4K@60Hz as specified in DisplayPort 1.4.

*** Supports 4K@60Hz as specified in HDMI 2.1



Expansion Slots

Intel® 12th Gen Processors

1 x PCIe 4.0 x16 slot

Intel® H610 Chipset

1 x PCIe 3.0 x1 slot



Storage

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

Intel® H610 Chipset:

M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0x4 mode)

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0x2 mode)

4 x SATA 6Gb/s ports



Ethernet

1 x Realtek 1Gb Ethernet



USB

Rear USB (Total 4 ports):

2 x USB 3.2 Gen 1 ports (2 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

Front USB (Total 6 ports):

1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1ports

2 x USB 2.0 headers support additional 4 USB 2.0 por



Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC*:

- Supports: Jack-detection, Multi-streaming, Front PanelJack-retasking

- Supports up to 24-Bit/192 kHz playback

Audio Features:

- Audio Shielding

- Premium audio capacitors

- Dedicated audio PCB layers

* A chassis with an HD audio module in the front panel isrequired to support 7.1 Surround Sound audio output.



Special Features

ASUS 5X PROTECTION III

- DIGI+ VRM

- LANGuard

- Overvoltage Protection

- SafeSlot Core

- Stainless-Steel Back I/O

ASUS Q-Design

- Q-DIMM

- Q-Slot

ASUS Thermal Solution

- Aluminum heatsink design

ASUS Lighting Control

- RGB header



Software Features



ASUS Exclusive Software:

Armoury Crate

AI Suite 3

- Performance And Power Saving Utility

TurboV EVO

EPU

DIGI+ VRM

Fan Xpert 2+

ASUS CPU-Z

IT Management software supported

- ASUS Control Center Express(ACCE)

Norton Anti-virus software (Free Trial version)

WinRAR

UEFI BIOS:

ASUS EZ DIY

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ Mode
