Product Highlights
• Supports Intel® Core™ Ultra Processors Series 2 with LGA1851 socket
• Intel B860 chipset with DDR5 memory support up to 8666+MT/s OC
• 4 × DDR5 DIMM slots support up to 256GB system memory
• Built-in Wi-Fi 6E, Bluetooth 5.3, and Realtek 2.5Gb Ethernet
• Supports PCIe 5.0 M.2 storage for high-speed SSD performance
• ASUS 5X Protection III, Aura Sync, and Q-Design features for reliable PC builds
Key Specifications
Product Type: Intel Motherboard
Form Factor: Micro-ATX
Model: ASUS PRIME B860M-A WIFI-CSM
CPU Support:
• Intel® Core™ Ultra Processors (Series 2)
• Socket: LGA1851
Chipset: Intel B860
Memory:
• 4 × DDR5 DIMM Slots
• Max Memory Capacity: 256GB
• Memory Speed: Up to 8666+MT/s OC
• Dual-Channel Mode Support
• Non-ECC, Unbuffered Memory Support
• Intel XMP Support
• On-Die ECC Function Support
Video Output:
• 2 × DisplayPort
• 1 × HDMI
• 1 × USB 20Gbps Type-C with DisplayPort Alt Mode
• DisplayPort: Up to 4K@60Hz / 4K@120Hz
• HDMI 2.1: Up to 4K@60Hz
Storage:
• 2 × M.2 Slots
• M.2_1: PCIe 5.0 x4
• M.2_2: PCIe 4.0 x4
• 4 × SATA 6Gb/s Ports
• Intel Rapid Storage Technology SATA RAID 0/1/5/10 Support
Audio: Realtek 7.1 Surround Sound
LAN:
• Realtek 2.5Gb Ethernet
• ASUS LANGuard
Wireless & Bluetooth:
• Wi-Fi 6E 2x2 802.11ax
• Supports 2.4GHz / 5GHz / 6GHz Bands
• Bluetooth 5.3
Back Panel I/O Ports:
• 1 × USB 20Gbps Type-C with DP Alt Mode
• 1 × USB 10Gbps Type-A
• 2 × USB 5Gbps Type-A
• 4 × USB 2.0 Type-A
• 2 × DisplayPort
• 1 × HDMI
• 1 × Wi-Fi Module
• 1 × Realtek 2.5Gb Ethernet Port
• 3 × Audio Jacks
Internal I/O Connectors:
• 1 × 4-pin CPU Fan Header
• 1 × 4-pin CPU OPT Fan Header
• 1 × 4-pin AIO Pump Header
• 3 × 4-pin Chassis Fan Headers
• 1 × 24-pin Main Power Connector
• 1 × 8-pin +12V CPU Power Connector
• 2 × M.2 Slots
• 4 × SATA 6Gb/s Ports
• 1 × USB 10Gbps Type-C Connector
• 1 × USB 5Gbps Header
• 1 × USB 2.0 Header
• 3 × Addressable Gen 2 Headers
• 1 × Aura RGB Header
• 1 × Clear CMOS Header
• 1 × Chassis Intrusion Header
• 1 × COM Port Header
• 1 × Front Panel Audio Header
• 1 × S/PDIF Out Header
• 1 × SPI TPM Header
• 1 × Front System Panel Header
• 1 × Thunderbolt™ / USB4® Header
Special Features:
• ASUS 5X Protection III
• DIGI+ VRM with DrMOS
• ESD Guards
• LANGuard
• Overvoltage Protection
• SafeSlot
• Stainless-Steel Back I/O
• Q-Antenna
• Q-Dashboard
• Q-DIMM
• Q-LED Core
• Q-Slot
• M.2 Heatsink
• VRM Heatsink Design
• ProCool
• Pre-Mounted I/O Shield
• Aura Sync
Software Features:
• Armoury Crate
• Aura Creator
• Aura Sync
• Fan Xpert 2+
• Power Saving
• ASUS DriverHub
• ASUS GlideX
• ASUS CPU-Z
• Norton 360 Deluxe 60 Days Free Trial
• WinRAR 40 Days Free Trial
BIOS: 256 (128+128) Mb Flash ROM, UEFI AMI BIOS
Manageability: WOL by PME / PXE
Operating System Support:
• Windows 11 22H2 & Later
• Windows 10 64-bit 21H2 & Later
Dimensions & Weight:
• Form Factor: Micro-ATX
• Product Dimensions: 24.4 × 24.4 cm
What's in the Box:
• 1 × ASUS PRIME B860M-A WIFI-CSM Motherboard
• 2 × SATA 6Gb/s Cables
• 1 × ASUS WiFi Q-Antenna
• 1 × M.2 Rubber Package
• 1 × Screw Package for M.2 SSD
• 1 × ACC Express Activation Key Card
• 1 × Quick Start Guide
Warranty: 3 Years Warranty
