Product Highlights
• Dual 3MP 2K Lenses: Two 3MP lenses provide simultaneous monitoring from different angles, with each lens supporting 2304 × 1296 resolution
• Fixed + Pan & Tilt Lens Design: Monitor a fixed area while remotely adjusting the second lens to follow activity
• AI Human & Vehicle Detection: Helps identify people and vehicles for more relevant security alerts
• Automatic Target Tracking: The pan-and-tilt lens can track detected moving targets
• Infrared & Warm-Light Night Vision: Supports night monitoring with infrared and warm-light illumination; range depends on lens and configuration
• Active Deterrence: Sound and light alarms help deter unwanted activity
• Two-Way Audio: Built-in microphone and speaker enable communication through the camera
• Wi-Fi 6 & Ethernet Connectivity: Supports 2.4GHz Wi-Fi and wired Ethernet for flexible installation
• IP66 Weather Resistance: Designed for outdoor use in challenging weather conditions
• microSD Local Storage: Supports a microSD card up to 256GB for local recording
• DMSS App Support: View live footage and receive alerts on compatible iOS and Android devices
Key Specifications
Brand: Dahua
Product Series: Picoo Dual
Model: DH-P3D-3F-PV
Product Type: Outdoor Dual-Lens Wi-Fi Pan & Tilt Network Camera
Camera Configuration: 3MP Fixed Lens + 3MP Pan & Tilt Lens
Maximum Resolution per Lens: 2304 × 1296 (3MP)
Image Sensor: 1/2.8-inch CMOS per lens
Video Compression: H.265
Day/Night Mode: Auto / Colour / Black & White
Wide Dynamic Range: DWDR
Fixed Lens:
- Focal Length: 2.8mm
- Aperture: F1.6
- Field of View: 110° diagonal / 95° horizontal / 53° vertical
- Manual Angle Adjustment: -10° to +15°
Pan & Tilt Lens:
- Focal Length: 6mm
- Aperture: F1.6
- Field of View: 62° diagonal / 53° horizontal / 29° vertical
- Pan Range: 0°–352°
- Tilt Range: 0°–90°
Night Vision Type: Infrared and Warm Light
Fixed Lens IR Distance: Up to 30m
Fixed Lens Warm-Light Distance: Up to 20m
Pan & Tilt Lens IR Distance: Up to 50m
Pan & Tilt Lens Warm-Light Distance: Up to 40m
Illuminators: 2 IR LEDs + 2 Warm-Light LEDs per camera lens
Built-in Microphone: Yes
Built-in Speaker: Yes
Two-Way Audio: Yes
Audio Compression: G.711a
Wi-Fi Standard: IEEE 802.11b/g/n/ax
Wi-Fi Frequency: 2.4GHz
Ethernet Port: 1 × RJ-45 10/100Mbps
Wi-Fi Pairing: Bluetooth-assisted pairing
Local Storage: microSD card up to 256GB
Management App: Dahua DMSS
Mobile Compatibility: Android / iOS
Power Supply: 12V DC
Basic Power Consumption: Approx. 2.3W
Maximum Power Consumption: Approx. 10W
Weather Protection: IP66
Operating Temperature: -30°C to +50°C
Operating Humidity: Up to 95% RH, non-condensing
Casing Material: Plastic
Product Dimensions: 159.4 × 119.1 × 210mm
Net Weight: Approx. 585g
Compatible with:
• Dahua DMSS mobile app
• 2.4GHz Wi-Fi networks
• Wired Ethernet networks
• Android smartphones and tablets
• Apple iPhone and iPad
• Compatible microSD cards up to 256GB
• Outdoor home, shop, driveway, garden and perimeter monitoring
Warranty : 2 Years Warranty
