GIGABYTE B850M FORCE WIFI6E V2 Micro ATX (mATX) AMD Gaming Motherboard | AMD AM5 Socket

RM599.00 RM579.00 SAVE 3%
Availability : In Stock Pre order Out of stock

Model: MOBO ONLY

MOBO ONLY
MOBO + 7500F TRAY
MOBO + 7800X3D TRAY
MOBO + 9800X3D
Add to Wishlist

Share on:

Overview

ย

Technical Specs :-

๐‚๐๐” :

Supports AMD Ryzenโ„ข 9000/ 8000/ 7000 Series Desktop Processors

ย

๐‚๐‡๐ˆ๐๐’๐„๐“ :

AMD B850

ย

๐Œ๐„๐Œ๐Ž๐‘๐˜ :

2 x DDR5 DIMM, Maximum Memory Capacity 128GB

Memory Support DDR5 9600 - 5600 (OC) MT/s

Dual channel memory architecture

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16

Support for AMD EXPO / XMP

ย

๐•๐ˆ๐ƒ๐„๐Ž ๐Ž๐”๐“๐๐”๐“ :

1x HDMI, supporting a maximum resolution of 4096x2160@60 Hz

1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

ย

๐„๐—๐๐€๐๐’๐ˆ๐Ž๐ ๐’๐‹๐Ž๐“ :

1 x PCI Express x16 slot (PCIEX16) , Supporting PCIe 5.0

1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4

ย

๐€๐”๐ƒ๐ˆ๐Ž :

Realtekยฎ Audio CODEC

ย

๐‹๐€๐ :

Realtekยฎ 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

ย

๐–๐ˆ๐‘๐„๐‹๐„๐’๐’ ๐‚๐Ž๐๐๐„๐‚๐“๐ˆ๐•๐ˆ๐“๐˜ :

MediaTek Wi-Fi 6E MT7902

Supports Bluetoothยฎ 5.3*

Support for 11ax 160MHz wireless standard

ย

๐’๐“๐Ž๐‘๐€๐†๐„ :

1x M.2 Up To PCI-E 5.0*

2x M.2 Up To PCI-E 4.0

4x SATA 6G

ย

USB

CPU:

- 1 x USB Type-Cยฎ port on the back panel, with USB 3.2 Gen 1 support

- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

- 1 x USB 2.0/1.1 port on the back panel

Chipset:

- 1 x USB Type-Cยฎ port with USB 3.2 Gen 1 support, available through the internal USB header

- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

- 5 x USB 2.0/1.1 ports (1 port on the back panel, 4 ports available through the internal USB headers)

ย

Internal I/O Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x CPU fan/water cooling pump header

1 x system fan header

1 x system fan/water cooling pump header

3 x addressable RGB Gen2 LED strip headers

1 x RGB LED strip header

3 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-Cยฎ header, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only)

1 x reset jumper

1 x Clear CMOS jumper

1 x Q-Flash Plus button

ย

๐‘๐„๐€๐‘ ๐ˆ/๐Ž :

1 x HDMI port (Note)

1 x DisplayPort (Note)

1 x PS/2 keyboard/mouse port

1 x USB Type-Cยฎ port, with USB 3.2 Gen 1 support

2 x USB 3.2 Gen 1 ports

1 x USB 3.2 Gen 2 Type-A port (red)

2 x USB 2.0/1.1 ports

1 x RJ-45 port

2 x antenna connectors (1T1R)

3 x audio jacks

ย

๐…๐Ž๐‘๐Œ ๐…๐€๐‚๐“๐Ž๐‘ :

Micro ATX Form Factor; 24.4cm x 24.4cm
