Product Highlights
• Supports Intel® Core™ Ultra Processors with LGA1851 socket
• Intel B860 chipset with DDR5 memory support up to 8800MT/s OC
• 2 × DDR5 DIMM slots support up to 128GB system memory
• PCIe 4.0 x16 slot for modern graphics card support
• Dual M.2 PCIe 4.0 SSD slots for high-speed storage performance
• Realtek 2.5GbE LAN and HDMI + DisplayPort video outputs
Key Specifications
Product Type: Intel Motherboard
Form Factor: Micro-ATX
Model: GIGABYTE B860M E DDR5
CPU Support:
• Intel® Core™ Ultra Processors
• Socket: LGA1851
Chipset: Intel B860 Express Chipset
Memory:
• 2 × DDR5 DIMM Slots
• Max Memory Capacity: 128GB
• Memory Speed Support:
DDR5 5600MT/s up to 8800MT/s (OC)
• Dual-Channel Memory Architecture
• ECC Unbuffered DIMM Support (Operates in Non-ECC Mode)
• Non-ECC Unbuffered DIMM Support
• Intel XMP Support
Onboard Graphics Output:
• 1 × HDMI 2.1 Port, Up to 4096 × 2160 @ 60Hz
• 1 × DisplayPort 2.1, Up to 3840 × 2160 @ 144Hz
Audio:
• Realtek Audio Codec
• High Definition Audio
• 2 / 4 / 5.1 / 7.1-Channel Audio
• S/PDIF Out Support
LAN:
• Realtek 2.5GbE LAN
Expansion Slots:
• 1 × PCIe 4.0 x16 Slot
• 1 × PCIe 3.0 x1 Slot
Storage:
• 2 × M.2 PCIe 4.0 x4/x2 SSD Slots
• 4 × SATA 6Gb/s Connectors
• RAID 0 / 1 / 5 / 10 Support
USB Support:
• 6 × USB 3.2 Gen 1 Ports
• 2 × USB 2.0 / 1.1 Ports on Back Panel
• 4 × USB 2.0 / 1.1 Ports via Internal Headers
Internal I/O Connectors:
• 1 × 24-pin ATX Main Power Connector
• 1 × 8-pin ATX 12V Power Connector
• 1 × CPU Fan Header
• 1 × CPU Fan / Water Cooling Pump Header
• 1 × System Fan / Water Cooling Pump Header
• 2 × Addressable RGB Gen2 Headers
• 2 × M.2 Socket 3 Connectors
• 4 × SATA 6Gb/s Connectors
• 1 × Front Panel Header
• 1 × Front Panel Audio Header
• 1 × S/PDIF Out Header
• 1 × USB 3.2 Gen 1 Header
• 2 × USB 2.0 Headers
• 1 × TPM Header
• 1 × Serial Port Header
• 1 × Clear CMOS Jumper
Back Panel Connectors:
• 1 × PS/2 Keyboard / Mouse Port
• 1 × HDMI Port
• 1 × DisplayPort
• 4 × USB 3.2 Gen 1 Ports
• 2 × USB 2.0 / 1.1 Ports
• 1 × RJ-45 LAN Port
• 3 × Audio Jacks
H/W Monitoring:
• Voltage Detection
• Temperature Detection
• Fan Speed Detection
• Water Cooling Flow Rate Detection
• Fan Fail Warning
• Fan Speed Control
BIOS:
• 1 × 256 Mbit Flash
• AMI UEFI BIOS
Unique Features:
• GIGABYTE Control Center (GCC)
• Q-Flash Support
• Smart Backup Support
Bundled Software:
• Norton Internet Security OEM Version
• LAN Bandwidth Management Software
Operating System Support:
• Windows 11 64-bit
• Windows 10 64-bit
Dimensions & Weight:
• Form Factor: Micro-ATX
• Product Dimensions: 24.4 × 21.5 cm
What's in the Box:
• 1 × GIGABYTE B860M E DDR5 Motherboard
• SATA Cable
• M.2 Screw
• User Documentation
Warranty: 3 Years Warranty
