Product Highlights
• Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700)
• GEN3 M.2 SSD STORAGE - The M.2 Gen3 x4 32Gb/s slot is designed to maximize NVMe based SSD performance; SSD storage reduces loading time
• WELL CONNECTED - Network hardware includes a 1Gbps LAN controller; Rear ports include USB 3.2 Gen 1 Type-A (5Gbps), HDMI 1.4 and VGA, and 7.1 HD Audio with Audio Boost
• DDR5 MEMORY, PCIe 4.0 x16 SLOT - 2 x DDR5 DIMM slots with Memory Boost isolated circuitry for overclocking (1DPC 1R, 5600 MHz); Primary PCIe x16 slot supports PCIe 4.0 (64GB/s) and includes Steel Armor
• MSI PRO series motherboards offer numerous possibilities for the needs of prosumers
• PASSIVE & AI COOLING - A chipset heatsinks provide passive cooling; Frozr AI cooling automatically adjusts system fan settings based on CPU & GPU temperatures
• MSI Motherboards offer a lot of practical and intelligent features for tinkerers
Key Specification:
Processor: Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
Processor socket:LGA1700
Chipset: Intel® H610 Chipset
Memory:
2x DDR5, Maximum Memory Capacity 96GB
Memory Support DDR5 5600 MHz (by JEDEC & POR)
Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory
Expansion Slot:
1x PCIe x16 slot (From CPU)
Supports up to PCIe 4.0 x16
1x PCIe x1 slot (From H610 chipset)
Supports PCIe 3.0 x1
Onboard Graphics
1x HDMI™ 1.4 with HDR port, supporting a maximum resolution of 4K 30Hz
1x VGA port, supporting a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
SATA Ports: 4x SATA 6Gb/s ports (From H610 chipset)
M.2 SSD Slot:
1x M.2 slot (Key M) (from H610 chipset)
Supports up to PCIe 3.0 x4
Supports up to SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
Audio: Realtek® ALC897 Codec, 7.1-Channel High Definition Audio
LAN: 1x Realtek® RTL8111H 1Gbps LAN controller
Power Connectors:
1x 24-pin ATX main power connector
1x 8-pin +12V power connector
Internal USB Connectors:
1x USB 3.2 Gen 1 5Gbps connector (From H610 chipset), Supports additional 2 USB 3.2 Gen 1 5Gbps ports
2x USB 2.0 Type-A connectors (From Hub-GL850G), Supports additional 4 USB 2.0 ports
Fan Connectors:
1x 4-pin CPU fan connector
2x 4-pin system fan connectors
System Connectors:
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Serial port connector
Jumpers: 1x Clear CMOS jumper
LED Features: 1x 4-pin RGB LED connector, 4x EZ Debug LED
Back panel ports:
HDMI™
VGA
Keyboard / Mouse
USB 3.2 Gen 1 5Gbps Type-A
LAN port
Audio connector
USB 2.0
Form Factor: M-ATX Form Factor, 23.6 cm x 20 cm
Warranty: 3 Years Warranty
